Inflatable Bladder Plastic Large PVC Pillow Flexible Water Storage Tank 100000L
PVC water tank is made of polymer composite. It has the characteristics of wear resistance, flame retardancy, good softness, easy folding, convenient storage, long service life and so on. The quality of the product reaches the advanced level of the international industry. It is mainly used for storing water and plays an important role in transporting water resources. It is especially suitable for water transportation in areas such as hills and mountains. Water tank can be customized for various types of vehicles, drought resistant water sac instead of the past heavy, easy to rust, short life of iron barrel and rubber barrels, in its transportation will not be due to bad road surface injury body, prolong the life of the car. When it is used, it will not be used normally because of seasonal changes. It can be folded and stored when it is not used.
Capacity
( m^3) |
Empty size
(m) |
Full height
(m) |
Net weight
(kg) |
Folding size
(m) |
| 1 | 2.2*1.9 | 0.4 | 14 | 0.7*0.65*0.2 |
| 5 | 3.8*3.2 | 0.6 | 50 | 1.0*0.8*0.75 |
| 10 | 4.5*4.4 | 0.8 | 85 | 0.9*0.75*0.4 |
| 50 | 8.5*7.0 | 1.1 | 220 | 1.5*0.9*0.65 |
| 100 | 11.0*9.5 | 1.2 | 390 | 1.5*1.1*0.7 |
| 200 | 16.6*9.5 | 1.6 | 630 | 2.0*1.1*0.9 |
| 400 | 17.2*15.7 | 1.7 | 1050 | 4.25*1.1*0.7 |
| 800 | 22.5*23 | 1.7 | 1720 | 5.7*2.1*0.7 |
Description
1, Capacity: 100000L
2, Material:PVC /TPU tarpaulin
3, Color: Any color can be customized
4, Model :WT-007
Technological process:
1. Base fabric high tenacity polyester
2. Coating flexible plasticized PVC with UV inhibitors
3. Polymer fabric with PVC coating clipped
4. High-frequency welding or heat sealing
Storage capacity, temperature:
1. Capacity(liter): 200~100000
2. Temperature(° C): -30~+70
3. Remarks: We are the factory. And we can manufacture water tank of any capacity, any colour, any size according to your requirements.
4.we can accept OEM order.
